Product Dimensions 31.9"h x 27"w x 31.5"d
The RT2A-FS-FS Steelheart Series Roll-Thru two section refrigerator with full stainless doors is a space saving workhorse. Stainless steel ramp, stainless steel interior rack guides, and insulated stainless steel floor. This efficient roll-thru refrigerator and front air flow design is perfect for hot/tight kitchens.Read More
Innovative air distribution system distributes air evenly to maintain product temperature
Enamel coated evaporator coil for extended life
Glass door front, stainless steel exterior (sides, top) and a stainless steel interior
Field reversible, spring assisted self closing door with stay open feature (no kit req’d)
One piece, full door length chrome handle per door
(1) stainless steel door with ABS interior liner
Insulated with 2″ CFC free, foamed in place polyurethane
(1) epoxy coated wire shelf adjustable in 1/2″ increments on anodized aluminum supports
Engineered to maintain food safe temperatures in 100°F ambient conditions
R290 refrigerant
(4) 2.25″ Stem Casters (2 with brakes) are standard
Optional Kits: 2.25″ or 6″ casters, epoxy wire shelf, stainless steel shelf, over shelves, foot pedals
Nominal Compres. of 988 BTU/hr at 1/6 HP
115v/60/1, 10 ft. cord and plug
General Specs | |
| Width (in.) | 27 |
| Depth (in.) | 31.5 |
| Height (in.) | 31.9 |
| Color | Stainless Steel |
| Depth w/Door Open 90 Degrees (in.) | 54.5 |
| Door Color | Clear |
| Handle Color | Stainless Steel |
| Manufacturer Warranty | 7 Years Labor, Parts and Compressor |
| Fingerprint Resistant Finish | No |
| Collection Code | UR27B |
| Door Panel Type | Glass |
| Color/Finish Name | Stainless Steel |
| Ice Maker | No |
| Depth Type | Counter Depth |
| Ice/Water Dispenser | No |
| Number of Doors | 1 |
| ENERGY STAR Certified | No |
| Commercial Use Approved | No |
| Custom Panel Ready | No |
| Installation Type | Freestanding |
| ADA Compliant | No |
| Smart Compatible | No |
| Shipping Depth (in.) | 31.5 |
| Shipping Width (in.) | 36 |
| Shipping Height (in.) | 35.5 |
| Voltage | 104-126 |
| Amp | 3 |
| Type of Refrigerator | Under The Counter Refrigerator |
| Refrigeration Dispenser Features | No Dispenser |
| Ice Maker Type | None |
| Overall Height (in.) | 31.9 |
| Garage Ready | No |
Other Dimensions | |
| Voltage | 115/60/1 |
| HACR Breaker | 15.0 Amps |
| Electrical Connection (NEMA) | 5-15P |
| Ambient Temperature Range | 45 to 100°F |
| Control Setpoint Range | 32° to 52°F |
| Energy Consumption (kWh/day) @NSF | 1.15 |
| Heat Rejection (BTU/Hr.) @NSF | 263 |
| Approximate Nominal Compres. BTU/HR (HP) | 988 (1/6HP) |
| Refrigerant / Charge Amount (oz) | R290 (2.3oz) |
| Door Opening Width x Height | 22.75” x 23” |
| Interior Storage Capacity (CF) (AHAM) | 6.21 ft3 |
| Shelf Dimensions (W x D) | 22” x 16” |
